Photo Info: ENGINE
Engine Type 449cc liquid-cooled single-cylinder Unicam four-stroke
Bore and Stroke 96.0 x 62.1mm
Compression Ratio 12.0:1
Induction 40.0mm Keihin© flat-slide
Ignition CD
DRIVE TRAIN
Transmission Wide-ratio five-speed
Final Drive #520 T-ring-sealed chain; 13T/51T
CHASSIS / SUSPENSION / BRAKES
Front Suspension 47.0mm inverted Showa® cartridge fork with 16-position rebound and 16-position compression damping adjustability; 12.4-inch travel
Rear Suspension Pro-Link® Showa single-shock with spring preload, 13-position [low-speed] and 3.5-turn [high-speed] compression damping and 17-position rebound damping adjustability; 12.4-inch travel
Front Brakes Single-disc with twin-piston caliper
Rear Brakes Single-disc
Front Tire 80/100-21
Rear Tire 110/100-18
DIMENSIONS
Rake 27.05 degrees
Trail 115 mm (4.5 inches)
Wheelbase 58.2 inches
Seat Height 37.9 inches
Ground Clearance 13.6 inches
Curb Weight 269 lbs (Includes all standard equipment, required fluids and a full tank of fuel—ready to ride)
Fuel Capacity 1.9 gallons
OTHER
Available Colors Red
Model ID CRF450X
|
